| EAN:4015080091950 | Type:On switch |
| Model Code:T0-1-15301/EZ | Screw size:M3.5, Terminal screw |
| Inscription:0 | Load rating:2 x Iₑ (with intermittent operation class 12, 25 % duty factor) 1.6 x Iₑ (with intermittent operation class 12, 40 % duty factor) 1.3 x Iₑ (with intermittent operation class 12, 60 % duty factor) |
| Switch type:On/Off switch | Fitted with::Retraction in 0-position 0 (off) position Black thumb grip and front plate |
| Product Name:Eaton Moeller® series T0 On switch | Suitable for:Branch circuits, suitable as motor disconnect, (UL/CSA) Front mounting |
| Actuator type:Toggle | Catalog Notes:Rated Short-time Withstand Current (Icw) for a time of 1 second |
| Product Width:48 mm | 10.2.5 Lifting:Does not apply, since the entire switchgear needs to be evaluated. |
| Catalog Number:009195 | Certifications:CSA CSA File No.: 012528 CSA-C22.2 No. 60947-4-1-14 IEC/EN 60947-3 CE UL 60947-4-1 UL File No.: E36332 CSA Class No.: 3211-05 IEC/EN 60204 UL UL Category Control No.: NLRV CSA-C22.2 No. 94 VDE 0660 |
| Product Height:48 mm | Product Weight:.101 kg |
| Safe isolation:440 V AC, Between the contacts, According to EN 61140 | Mounting method:Center mounting |
| Number of poles:Single-pole | Switching angle:45 ° |
| Pollution degree:3 | Product category:Control switches |
| Shock resistance:15 g, Mechanical, According to IEC/EN 60068-2-27, Half-sinusoidal shock 20 ms | Actuator function:With 0 (Off) position Spring-return to 0 Momentary |
| Climatic proofing:Damp heat, constant, to IEC 60068-2-78 Damp heat, cyclic, to IEC 60068-2-30 | Front shield size:48x48 mm |
| Mounting position:As required | Tightening torque:8.8 lb-in, Screw terminals 1 Nm, Screw terminals |
| Number of contacts:1 | 10.2.7 Inscriptions:Meets the product standard's requirements. |
| Device construction:Built-in device | Operating frequency:1200 Operations/h |
| Degree of protection:NEMA 12 IP65 NEMA 1 | Lifespan, mechanical:400,000 Operations |
| Overvoltage category:III | Product Length/Depth:96 mm |
| Uninterrupted current:Rated uninterrupted current Iu is specified for max. cross-section. | 10.10 Temperature rise:The panel builder is responsible for the temperature rise calculation. Eaton will provide heat dissipation data for the devices. |
| Number of contact units:1 | 10.2.6 Mechanical impact:Does not apply, since the entire switchgear needs to be evaluated. |
| 10.13 Mechanical function:The device meets the requirements, provided the information in the instruction leaflet (IL) is observed. | 10.11 Short-circuit rating:Is the panel builder's responsibility. The specifications for the switchgear must be observed. |
| Number of switch positions:2 | 10.2.2 Corrosion resistance:Meets the product standard's requirements. |
| Control circuit reliability:1 failure per 100,000 switching operations statistically determined, at 24 V DC, 10 mA) | Heat dissipation capacity Pdiss:0 W |
| Short-circuit protection rating:20 A gG/gL, Fuse, Contacts | 10.9.3 Impulse withstand voltage:Is the panel builder's responsibility. |
| Rated uninterrupted current (Iu):20 A | Degree of protection (front side):IP65 NEMA 12 |
| Safety parameter (EN ISO 13849-1):B10d values as per EN ISO 13849-1, table C.1 | Terminal capacity (solid/stranded):1 x (1 - 2.5) mm² 2 x (1 - 2.5) mm² |
| Voltage per contact pair in series:60 V | 10.12 Electromagnetic compatibility:Is the panel builder's responsibility. The specifications for the switchgear must be observed. |
| Ambient operating temperature - max:50 °C | Ambient operating temperature - min:-25 °C |
| 10.4 Clearances and creepage distances:Meets the product standard's requirements. | 10.5 Protection against electric shock:Does not apply, since the entire switchgear needs to be evaluated. |
| Rated impulse withstand voltage (Uimp):6000 V AC | 10.3 Degree of protection of assemblies:Does not apply, since the entire switchgear needs to be evaluated. |
| 10.8 Connections for external conductors:Is the panel builder's responsibility. | 10.9.2 Power-frequency electric strength:Is the panel builder's responsibility. |
| Rated operating voltage (Ue) at AC - max:690 V | Rated short-time withstand current (Icw):320 A, Contacts, 1 second |
| Short-circuit current rating (high fault):10 kA, SCCR (UL/CSA) 20 A, Class J, max. Fuse, SCCR (UL/CSA) | Terminal capacity (flexible with ferrule):2 x (0.75 - 2.5) mm², ferrules to DIN 46228 1 x (0.75 - 2.5) mm², ferrules to DIN 46228 |
| Short-circuit current rating (basic rating):50A, max. Fuse, SCCR (UL/CSA) 5 kA, SCCR (UL/CSA) | Number of contacts in series at DC-23A, 24 V:1 |
| Number of contacts in series at DC-23A, 48 V:2 | Number of contacts in series at DC-23A, 60 V:3 |
| Rated conditional short-circuit current (Iq):6 kA | Number of contacts in series at DC-21A, 240 V:1 |
| Number of contacts in series at DC-23A, 120 V:3 | Number of contacts in series at DC-23A, 240 V:5 |
| Rated operational current (Ie) at AC-3, 500 V:9 A | Rated operational power at AC-3, 415 V, 50 Hz:5.5 kW |
| Rated operational power at AC-3, 690 V, 50 Hz:4 kW | Ambient operating temperature (enclosed) - max:40 °C |
| Ambient operating temperature (enclosed) - min:-25 °C | Rated operational current (Ie) at AC-21, 440 V:20 A |
| Rated operational current (Ie) at DC-21, 240 V:1 A | Rated operational current (Ie) at DC-23A, 24 V:10 A |
| Rated operational current (Ie) at DC-23A, 48 V:10 A | Rated operational current (Ie) at DC-23A, 60 V:10 A |
| Rated operational current (Ie) at AC-23A, 230 V:13.3 A | Rated operational current (Ie) at AC-23A, 500 V:13.3 A |
| Rated operational current (Ie) at AC-23A, 690 V:7.6 A | Rated operational current (Ie) at DC-23A, 120 V:5 A |
| Rated operational current (Ie) at DC-23A, 240 V:5 A | Rated operational power at AC-23A, 400 V, 50 Hz:5.5 kW |
| Rated operational power at AC-23A, 500 V, 50 Hz:7.5 kW | Rated operational power at AC-23A, 690 V, 50 Hz:5.5 kW |
| Switching capacity (main contacts, general use):16 A, Rated uninterrupted current max. (UL/CSA) | 10.2.4 Resistance to ultra-violet (UV) radiation:UV resistance only in connection with protective shield. |
| 10.7 Internal electrical circuits and connections:Is the panel builder's responsibility. | Assigned motor power at 115/120 V, 60 Hz, 1-phase:.5 HP |
| Assigned motor power at 200/208 V, 60 Hz, 1-phase:1 HP | Assigned motor power at 200/208 V, 60 Hz, 3-phase:3 HP |
| Assigned motor power at 230/240 V, 60 Hz, 1-phase:1.5 HP | Assigned motor power at 230/240 V, 60 Hz, 3-phase:3 HP |
| Assigned motor power at 460/480 V, 60 Hz, 3-phase:7.5 HP | Assigned motor power at 575/600 V, 60 Hz, 3-phase:7.5 HP |
| Heat dissipation per pole, current-dependent Pvid:.6 W | Equipment heat dissipation, current-dependent Pvid:0 W |
| Rated operational power star-delta at 500 V, 50 Hz:7.5 kW | Rated operational power star-delta at 690 V, 50 Hz:5.5 kW |
| Static heat dissipation, non-current-dependent Pvs:0 W | Rated operational power at AC-23A, 220/230 V, 50 Hz:3 kW |
| Switching capacity (auxiliary contacts, pilot duty):A600 (UL/CSA) P300 (UL/CSA) | Terminal capacity (solid/flexible with ferrule AWG):18 - 14 |
| Rated operational current (Ie) at AC-3, 660 V, 690 V:4.9 A | Switching capacity (auxiliary contacts, general use):10A, IU, (UL/CSA) |
| 10.6 Incorporation of switching devices and components:Does not apply, since the entire switchgear needs to be evaluated. | Rated operational current (Ie) at AC-23A, 400 V, 415 V:13.3 A |
| Rated operational power star-delta at 220/230 V, 50 Hz:5.5 kW | Rated operational power star-delta at 380/400 V, 50 Hz:7.5 kW |
| 10.2.3.1 Verification of thermal stability of enclosures:Meets the product standard's requirements. | 10.9.4 Testing of enclosures made of insulating material:Is the panel builder's responsibility. |
| Rated operational current (Ie) star-delta at AC-3, 230 V:20 A | Rated operational current (Ie) star-delta at AC-3, 400 V:20 A |
| Rated operational current (Ie) star-delta at AC-3, 500 V:15.6 A | Rated operational current (Ie) star-delta at AC-3, 690 V:8.5 A |
| Rated breaking capacity at 500 V (cos phi to IEC 60947-3):80 A | Rated operational current (Ie) at AC-3, 220 V, 230 V, 240 V:11.5 A |
| Rated operational current (Ie) at AC-3, 380 V, 400 V, 415 V:11.5 A | Rated breaking capacity at 220/230 V (cos phi to IEC 60947-3):100 A |
| Rated breaking capacity at 400/415 V (cos phi to IEC 60947-3):110 A | Rated breaking capacity at 660/690 V (cos phi to IEC 60947-3):60 A |
| Rated making capacity up to 690 V (cos phi to IEC/EN 60947-3):130 A | Rated operational current for specified heat dissipation (In):20 A |
| Rated operational current (Ie) at DC-13, control switches L/R = 50 ms:10 A | Rated operational current (Ie) at DC-1, load-break switches l/r = 1 ms:10 A |
| 10.2.3.2 Verification of resistance of insulating materials to normal heat:Meets the product standard's requirements. | 10.2.3.3 Resist. of insul. mat. to abnormal heat/fire by internal elect. effects:Meets the product standard's requirements. |
